Specifications
Kingtouch Technology Group is in producing Surface Acoustic Wave(SAW) screen, Multi- Infrared screen/IR Panel frame, LCD Kiosk, Interactive foil, resistive screen, LCD Panel PC/ Computor/ bezel Monitor, Tablet PC, Optical screen and Capacitive screen, Any size of panel we can customized for you. Just let us know the requirement. For Multi- IR Panel, we can offer Dual-(2 points), 6 points, 8 points, 10 points, 16 points and 32 points, No ghost point. Etc.
Product Description:
Infrared(IR) screen operate on the mechanism of infrared LEDs arranged in arrays on two adjacent bezel edges of the PCB with photo sensors placed on the two opposite edges functioning as transmitters and receivers. The LEDs emit infrared rays simultaneously to form a grid of rays across the display. When the user wishes to send a signal through , he/she can do so by interrupting the light beams with a physical object. Since every infrared LED is independent, the screen is able to achieve positioning by analyzing the decrease in light at the corresponding photo sensors. The signal is then processed by the control circuitry and sent to the PC For Multi-touch coordinates of the event to be displayed on screen or to be utilized by other software for the signal operation.
Advantage:
--Multi- ( 6 points )
-- IP65 Available
--Support zoom in/out, display rotation
--Withstands severe environments
--Stable, no-drift calibration performance
--Vandal- and abrasion-resistant screens, ideal for relevant applications
--Parallax-free performance for rugged displays
--Sealable against contaminants
--Operable in various light conditions, indoor and outdoor
Application:
--Point-of-information kiosks
--Electronic catalogs
--Gaming, POS, ATM, lottery, and amusement
--Industrial control rooms
--Computer-based training
Specification:
Size |
General Size | 30 inch to 150inch |
Fit in with | Panel display device |
Performance |
Touch Mode | Multi-, drag, draw-line, rotate, zoom in/out |
Resolution(Interpolation) | 32767 * 32767 |
Linearity Error | <1.5mm |
Response Speed | <15ms |
Mechanical |
Input Method | Finger or gloved hand (rubber ,cloth or leather) |
Touch Times | Unlimited |
Touch Activation Force | No minimum activation force is required |
Minimum Object | 2.5 mm X 2.5 mm |
Vandal-proof | No break by 1-pound steel ball dropping from 130 cm high |
Surface Durability | Surface durability is that of glass, Mohs\\\' hardness rating of 7 |
Optical |
Glass: | Without glass, 4mm glare, AG (anti-glare), or AR (anti-reflective) glass optional |
Light Transmission | 92% |
Gloss | Antiglare surface (curved or flat): 95 ± 15 gloss units or 65 ± 15 gloss units |
Environmental |
Temperature | Operating Range: -20°C ~ 70°C; |
Storage Range: -40°C ~ 85°C |
Relative Humidity | Operating Range: 0%~90% RH (no dew falls) |
Storage Range: 0% to 95% RH (no dew falls) |
Altitude | Up to 3,000m |
Ambient Light | Direct sunlight 90°to ±30° to the display surface detection operational |
Direct sunlight all angles to display surface Free of false reports |
Electrical |
Operation Voltage | Typical +DC 5V, +4.75V to +5.25V |
Power Supply | Size under 52”(include 52”)USB or PS/2 Interface, power ripple .200mV rms |
Size above 52”(52” not included): external AC-DC power adaptor |
Interface | Full Duplex USB 2.0 (Full Speed) Plug and play compatible |
Serial RS-232. Baud Rate: 9600, 8 Data Bits, 1 Stop Bit, No Parity |
Current | Typical ; 350mA, maximum |
Power | <1.5W, operating current<300mA |
Electrostatic Protection | 15 kV air / 8 kV contact discharges (EN61000-4-2,1995 :Level 4) |
Controller | Integration inside panel |
Agency Approvals | CE, FCC, Rohs |
Operating System |
Operation System: Perfectly Support Windows XP / / Linux |
