CAN BUS 2012 ELM 327 elm327 USB interface supports

ELM 327 USB interface supports all OBDII protocols
OBD-II Software for ELM327 is a free program that allows you to use your PC and a hardware interface to get the information from your car′s computer.
The program is very user-friendly, and easy to learn. It is also very easy to install:
simply extract the files into a folder on your computer′s hard drive, and you′re ready to go. To uninstall the program, simply delete the entire contents of the folder where the program resides.

Specifications

ELM 327 USB interface supports all OBDII protocols

ELM 327 USB interface pictures:





ELM 327 USB interface supports all OBDII protocols


OBD-II Software for ELM327 is a free program that allows you to use your PC and a hardware interface to get the information from your car's computer.

The program is very user-friendly, and easy to learn. It is also very easy to install:

simply extract the files into a folder on your computer's hard drive, and you're ready to go. To uninstall the program, simply delete the entire contents of the folder where the program resides.

The software supports two platforms - DOS and Windows.

OBD-II Protocols:



- ISO15765-4 (CAN)

- ISO14230-4 (KWP2000)

- ISO9141-2

- J1850 VPW

- J1850 PWM


Output protocol: RS232


Baud rate: 9600 or 38400

Indicator LEDs: OBD Tx/Rx, RS232 Tx/Rx, Power

Operating voltage: 12V, internal protection from short circuits/overvoltages

Nominal idle current: 45 mA


Features:

The program lets you perform the following operations:

Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).

Clear trouble codes and turn off the MIL ("Check Engine" light)


Display current sensor data, including:



- Engine RPM

- Calculated Load Value

- Coolant Temperature

- Fuel System Status

- Vehicle Speed

- Short Term Fuel Trim

- Long Term Fuel Trim

- Intake Manifold Pressure

- Timing Advance

- Intake Air Temperature

- Air Flow Rate

- Absolute Throttle Position

- Oxygen sensor voltages/associated short term fuel trims

- Fuel System status

- Fuel Pressure

- Many others...


Upcoming Features:

- Data graphing and logging

- Freeze Frame data

- Continuous and Non-Continuous Oxygen Sensor test results


Free software:


Scantool.net

- GM Mode 22 Scan Tool by Terry

- OBD Gauge for PalmOS and Pocket PC by Dana Peters

- OBD by Jonathan Senkerik

- OBD-II ScanMaster by Wladimir Gurskij (ScanMaster 3.52 - local )

- obd2crazy.com

- OBD2 Scantool by Ivan Andrewjeski

- OBDII for ELM322 by David Huffman

- pyOBD by Donour Sizemore for MacOSX and Linux

- RDDTC by Pete Calinski

- Real Scan by Brent Harris

- ScanTest for Pocket PC by Ivan Ganev aka a-ser

- wOBD by WDT


Aavailable :


ST12001/02/03W203 C200K (ISO)

X5 2002 (ISO) Chevrolet Aveo (ISO)

Citroen C3 2004 (ISO) ? Daihatsu YRV 2005 (ISO)

Daihatsu YRV 2006 (ISO)

Fiat Tipo 2002 (ISO)

New?ocus 2006(CAN)


Accord 2006 JDM (ISO)


Accord Euro R 2004 JDM (ISO)

City GD8 (ISO)

Civic ES 1.6A (ISO)

Integra Type R DC5 JDM (ISO)

Jazz 1.4M (ISO)


Accent 2004 (ISO)


Getz 1.3A 2004 (ISO)

Getz 1.6M 2004 (ISO)

Matrix 2004 (ISO)

HyundaiSanta Fe2.4A (ISO)

Sonata GLS (ISO)

Sonata 2005 (ISO)

Tuscani FX (ISO)

Kia Carens 2005 (ISO)

Kia Magentis 2005 (ISO)

KiaRioLS (ISO)

Kia Sorento SUV 2005 (ISO)

Lexus es300 Mazda 2 (CAN)

Mazda 5 (CAN)

Mazda 6 (CAN)

Mazda Premacy 2001 (ISO)

Mazda RX8 (CAN)

Mitsubishi Colt 2003 (ISO)

Mitsubishi Colt Plus 2005 (ISO)

Mitsubishi Eclipse(GST----- Car can be tested for the year 1995-2000;RS/GS----1994-1996 GS all can do; Car for the year 1996-2000,only have speed and TPS,can clear the DTCS)

Mitsubishi Lancer Evolution IX 2006 (ISO)

Mitsubishi Pajero 3.5 V6 2006 (ISO)

Sunny B14 (ISO)

Sunny VIP FB15 (ISO)

X-Trail 2.0L 2004 (ISO)

X-Trail 2.5L 2004 (ISO)

206 2001 –Only can show RPM

206 (ISO)

307 (ISO)

407 (ISO)

Megane II 2005 (ISO)

Kangoo 2006 (ISO)

Subaru Impreza 1.6TS 2002 (ISO)

Subaru Impreza WRX 2005 (ISO)

ToyotaCamry 2.0A 2004 (ISO)

ToyotaCamry 2.4A 2005 (ISO)

ToyotaCorolla Altis 1.6A 2005 (ISO)

ToyotaCorolla GLXi G8 1999 (ISO)

ToyotaCorolla G9 2002 (ISO)

ToyotaVios 2004 (ISO)


Not available veichles:


Mazda 323 Protege 2003 (OBD-I)

Mitsubishi Lancer 1.6M 2006

Sunny (N16)

Cefiro (Teana) 2005

sentra 1.8 2000/2005

Cefiro (Teana) 2005

Proton Perdana V6

Subaru Legacy GT 2005

Toyotacamry 2002

ToyotaWish JDM (Missing Pin 5 in DLC)

ToyotaIST JDM (Missing Pin 5 in DLC)

Toyotaaltis 1.8 2004

206 2000

Jimny 1.3 2000

engine


Package includes:

1. One elm327 USB interface
2. One CD software
