Specifications
Because of registration fee and first packing weight, more quantity, cheaper shipping cost for 1 piece.
Below it is an example for different quantity shipped by China Post Air Mail |
| quantity(Pcs) | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 |
| shipping cost(US$/1 piece) | 4.31 | 2.52 | 1.92 | 1.62 | 1.44 | 1.33 | 1.24 | 1.18 | 1.13 | 1.09 |
Company Profile
Shenzhen Qihan Power ,Ltd was found in 2006 and We always devote ourselves to reseaching, devoloping and manufacture high quality LED diver, to build our outstanding national brand and contribute to our society.
Our company specializes in all kinds of LED constant current driver from 1 to 400 watts including built-in driver, out-setting case driver and waterproof driver which are used widely in a variety of LED lighting industry, such as E27/GU10 LED bulb, /T10 tube, MR16 spot light, ceiling light, down light, candle light, streetlight, road lamp, panel light, tunnel light, miner light and floodlight etc. A team who holds over ten yeas experience in LED dirver design and quality control, carefully chosen IC , capacitors and other electronic components, high-precision constant current, high power factor and CE certification guarantee our products high quality, high energy change efficiency, long life and safety.
Up to now, our products were sold to all over the world; brand Qihan is popular; our credibility reputation and quality are receiving more recognition and our market share doubled every year since 2009. We promise that we will provide better products and better sevice to our society as we grow with our customer .
Product parameter:
model: QH-LK8~12X1 | type: dimmable housing | certification: |
input voltage: AC 190~240V | out put voltage: DC 21~42V | output dimmable current: 3~290mA |
power: 8~12W | efficience: 87% | current pricision: +/-3% |
noise voltage: <2% | power factor: | waterproof class: |
modulation mode: PWM | size(L*W*H): 88*39*24mm | ambient temperature: -40~+85 degrees |
Product advantage:
1, Advanced IC, brand capacitor specially used for LED and other high quality electronic component were used to assure output current high accuracy, long life and stability of lamp and light.
2, The latest circuit design of higher energy change efficience guarantees a better energy saving effect.
3, Input and output of our driver is isolated, protection circuit is designed in the condition of open circuit, short circuit, over load and overheat to make our product more reliable and safer.
Application:
E27/GU10 bulb lamp, down lamp etc. where dimmable housing driver is needed.
Usage:
This model can be used to light 8 to 12 Series-1 Parallel connection of 1-watt LED. The brown and blue wires should be connected to a triac dimmer, and the other side to LED lamp; the red one must be connected to positive electrode of lamp and the black to negative.
Warning:
The LED driver should be installed by certificated technician in case of electric and product damage.
Warranty:2 years
LED driver dimmable 3W 4W 5W 6W 7W 10mA~290mA 3-7S-1PX1 power supply lighting transformer QiHanUS$ 1.81/piece |
LED driver dimmable 3W 4W 5W 6W 7W 10mA~290mA 3-7S-1PX1 power supply lighting transformer free shippingUS$ 19.90/lot
5 pieces / lot |
LED driver dimmable 3W 4W 5W 6W 7W 10mA~290mA 3-7S-1PX1 power supply lighting transformer free shippingUS$ 27.80/lot
10 pieces / lot |
T8/T10 tube LED driver 6W 10W 12W 15W 16W 18W 0.1A 0.15A 0.18A 0.2A 0.25A 0.3A 21V~100V power supply lighting transformer QiHanUS$ 1.61/piece
|
|
