Main Features:
High resolution, high sensitivity and high S/N ratio.
Low illumination, high quality image.
With 1/3 `` CMOS pick-up device and 3.6mm lens.
Made of high-quality aluminum.
Small size and lightweight, convenient to fix and use.
Specifications:
|
Pick-up Device
|
1/3 ``CMOS
|
|
Lens
|
3.6mm
|
|
TV System
|
PAL
|
|
Picture Element
|
752(H) * 582(V)
|
|
Horizontal Resolution
|
380TV Lines
|
|
Minimum Illumination
|
0.5LUX / F1.2
|
|
Synchronous System
|
Internal Synchronization
|
|
Electronic Shutter
|
1/50(1/60)1/100.000 sec
|
|
Backlight Compensation
|
Auto
|
|
Auto Gain Control
|
Auto
|
|
White Balance
|
Auto
|
|
S/N Ratio
|
>=48dB
|
|
Gamma Correction
|
0.45
|
|
Video Output
|
1.0Vp - p/75 ohm(BNC)
|
|
Operation Temperature
|
(-20) degree - (50) degree
|
|
Power Supply
|
DC12V 500mA
|
| Item Size |
9.5 * 9.5 * 5cm
|
| Item Weight |
202g
|
| Package Size |
10 * 10 * 8.5cm
|
| Package Weight |
245g
|
Package including:
1 * CCTV Camera
|
